300kv X Ray Flaw Detector Industrial Generator NDT Equipment X Ray Machine

300kv X-ray Flaw Detector Industrial Generator NDT Equipment X Ray Machine

Main introduction:

Advanced 300kV Industrial Radiography System (RD-300LG)‌

‌In order to improve the efficiency of thick-walled metal detection, Huiwei developed the industry-renowned RD-300LG series products in recent years. The equipment can work continuously for 100 minutes, with a working efficiency of more than 5 times that of its peers, can penetrate 80mm steel plates, and has extremely stable quality. It can adapt to various extreme weather and special geographical environments, and is a solution for long-distance pipelines and super-large containers. The market is in short supply and has been out of stock for a long time. It occupies about 70% of the market share in the field of long-distance pipeline detection in China, and its main competitors are high-frequency series products from German and American companies. Compared with foreign high-frequency products, RD-300LG has super long continuous working time (100 minutes), super strong penetration ability, strong environmental adaptability and stability. At the same time, Hivi has a 7*24-hour all-weather technical service system. Compared with the two to three months repair cycle of European and American manufacturers, Huiwei will send a spare machine within 24 hours after the equipment fails, and complete the equipment repair within 3-5 working days, and the repair cost is only one-tenth of that of European and American competitors.

RD-300LG Technical Parameter

Item	Technical Data
	AC Power	AC 220V+/-10%, 50Hz
Output	Tube current	5mA
	High voltage transfer input voltage fluctuation	+/- 1%
X Ray Generator	Cooling method	Force air cooling
	Insulated method	SF6 gas insulation
	Soft working pressure (20ºC)	0.35~0.45Mpa
Working Condition	Temperature	-30-40ºC
	Relative Humidity	<85%
	Altitude	1000m
Max Penetration Condition	Steel	A3(mm)
	Focal length	600m
	Exposure	≤30mAmin
	Film	Double-sided lead foil sensitization
	Darkroom treatment	20+/-2ºC, 5min
	Optic density	D≥2.0
The controller	Size
	Weight
	Timing error	5min +/- 10%
Working Rate	Working & rest 2:1 working rate, the max exposure time 9.5min

Company profile

We have been focusing on the innovation and development of industrial X-ray equipment for more than 30 years. After many years of development, we have successfully developed the RD28/35 series of portable X-ray machines, which are small in size, light in weight and have a low failure rate. After years of development, the RD28/35 series has become the main non-destructive testing equipment for natural gas and oil pipelines, power systems, military shipyards, nuclear power plants, chemicals, boiler pressure vessel inspections, and valve manufacturing industries.
